Name: Sewer Structures

Display Field: dropMH

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description:

Service Item Id: 57eef5c59d124fc28392ae776b4b168f

Copyright Text:

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 6030142.4745050315
YMin: 1970921.8507067028
XMax: 6066983.6083168
YMax: 1995204.0402575505
Spatial Reference: 102645  (2229)  VCSWkid(5703)  LatestVCSWkid(5703)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: status
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSMSCircle
Color: [130, 130, 130, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 0
Default Label:
UniqueValueInfos:
• Value: ABAN
  Label: ABAN
  Description: N/A
  Symbol:
  Style: esriSMSSquare
  Color: [232, 190, 255, 255]
  Size: 6.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 1
• Value: LIVE
  Label: LIVE
  Description: N/A
  Symbol:
  Style: esriSMSSquare
  Color: [132, 0, 168, 255]
  Size: 6.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 1
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• comments ( type: esriFieldTypeString, alias: Comments, length: 50 )
• covDiam ( type: esriFieldTypeString, alias: Cover Diameter, length: 10 )
• depth ( type: esriFieldTypeString, alias: Structure Depth (OMS), length: 10 )
• hpSurvey ( type: esriFieldTypeString, alias: HP Survey, length: 1 )
• instDate ( type: esriFieldTypeString, alias: Installation Date (OMS), length: 19 )
• invElev ( type: esriFieldTypeDouble, alias: Invert Elevation (OMS) )
• material ( type: esriFieldTypeString, alias: Material Type (OMS), length: 50 , Coded Values: [Vitrified Clay Pipe: Vitrified Clay Pipe] , [Polyvinyl Chloride: Polyvinyl Chloride] , [Polyethylene: Polyethylene] , ...9 more... )
• mhDiam ( type: esriFieldTypeDouble, alias: Manhole Diameter )
• owner ( type: esriFieldTypeString, alias: Owner, length: 15 , Coded Values: [CITY: City] , [COUNTY: County] )
• planNumber ( type: esriFieldTypeString, alias: Plan Number (OMS), length: 200 )
• rehabDate ( type: esriFieldTypeDate, alias: Rehab Date (OMS), length: 8 )
• rehabMaterials ( type: esriFieldTypeString, alias: MH Rehab Materials, length: 20 , Coded Values: [Epoxy/Polymer: Epoxy/Polymer] , [Plastic: Plastic] , [CIPP: CIPP] , ...1 more... )
• rim ( type: esriFieldTypeDouble, alias: Rim Elevation )
• status ( type: esriFieldTypeString, alias: Structure Status, length: 50 , Coded Values: [LIVE: LIVE - Feature is in service] , [ABAN: ABAN - Feature is abandoned (not in service)] )
• omsID ( type: esriFieldTypeString, alias: OMS ID (OMS), length: 15 )
• structureType ( type: esriFieldTypeString, alias: Structure Type, length: 30 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• creekCrossing ( type: esriFieldTypeSmallInteger, alias: Creek Crossing (OMS) )
• dropManhole ( type: esriFieldTypeSmallInteger, alias: Drop Manhole (OMS) )
• levelSensor ( type: esriFieldTypeSmallInteger, alias: Level Sensor (OMS) )
• lidDiameter ( type: esriFieldTypeDouble, alias: Lid Diameter (OMS) )
• mhLined ( type: esriFieldTypeSmallInteger, alias: MH Lined (OMS) )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
