Parent Layer: Utility Stormdrain

Name: Storm Water Drainage easements

Display Field: adoption

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: OverviewThis feature service contains polygon features that represent utility easement areas. It supports GIS-based review and management of mapped easement boundaries associated with utility infrastructure and related rights of way for the staff of the City of Santa Barbara.Key AttributesAdoption status provides the current record status for each easement.Comments captures notes and supporting details.Date records the associated effective or reference date.Easement width documents the recorded width where available.Reference link and source data identify supporting documentation and provenance.Easement type classifies the kind of utility easement.GIS UseThe layer can support map display, spatial analysis, and recordkeeping for utility easement management, helping users identify easement extents, review associated documentation, and integrate the features into planning or asset management workflows.Last Update: 2026

Service Item Id: 3eaf8cdba58048e899c4b018d3c1a827

Copyright Text: Public Works, City of Santa Barbara

Default Visibility: false

MaxRecordCount: 4000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 6006460.120163217
YMin: 1970767.0347918123
XMax: 6069539.13442488
YMax: 1997915.033645317
Spatial Reference: 102645  (2229)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [0, 0, 0, 0]
Outline:
Style: esriSLSSolid
Color: [255, 115, 223, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: [type] CONCAT (" Drain Easement")
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: center
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 6
Font Family: Arial
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 0.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• adoption ( type: esriFieldTypeString, alias: Adoption Status, length: 255 )
• comments ( type: esriFieldTypeString, alias: Comments, length: 255 )
• date ( type: esriFieldTypeDate, alias: Date, length: 8 )
• easementWidth ( type: esriFieldTypeString, alias: Easement Width, length: 10 )
• link ( type: esriFieldTypeString, alias: Reference Link, length: 255 )
• sourceData ( type: esriFieldTypeString, alias: Source Data, length: 255 )
• type ( type: esriFieldTypeString, alias: Easement Type, length: 255 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
